Water-Cooling Air-Cooling And Evaporative Cooling In Industrial Air Conditioner For Optimal Cooling

Water-Cooling Air-Cooling And Evaporative Cooling In Industrial Air Conditioner For Optimal Cooling

Brand Name:	Dahanfeng
Model Number:	DHF-A-C16FPB-II 1
MOQ:	30 sets
Price:	US$1930/set/Factory price
Payment Terms:	T/T , D/A, D/P, L/C
Supply Ability:	80~150 sets in 15~25 working days

Detail Information

Product Description

Detail Information

Place of Origin:

Guangdong, China

Certification:

3C, CE, RoHs,IS09001,ISO14001,CEP

Power Supply:

380 V ~3N/50 Hz

Circulating Air Flow:

5600 M³/h

Distance Of Cold Air:

≈15 M

Condensate Pipe:

DN20

Applying Area:

150~210 ㎡

Noise:

68 DB(Grade A)

Dimension Of Inner Unit:

1800*870*400 Mm

Weight Of Inner Uint:

34 KG

Full Pressure:

200 Pa

Nominal Cooling Power:

22.4 KW

Rated Cooling Power:

6 KW

Max Running Power:

9 KW

Max Running Current:

16.1 A

Compressor Type:

Enclose Hermetic Rotor

Refill Pipe:

DN20

Drain Pipe:

DN20

Applying Ambient Temperature:

16°C~43°C

Out Unit Weight:

154 Kg

Dimension Of Out Unit:

1230*530*1680 Mm

Refrigerant:

R22

Circulating Air Flow Of Out Unit:

8400 M³/h

Packaging Details:

Carton + wooden frame(option)

Highlight:

Water-Cooling Industrial Air Conditioner

Evaporative Cooling Industrial Air Conditioner

DN20 Industrial Air Conditioner

Product Description

Greenhouse Emission Reduction With Low Carbon Energy Saving Air Conditioner

An energy-saving air conditioner is a type of air conditioning system designed to minimize energy consumption while providing effective cooling or heating.

Smart Control and Optimization Features

Improved Heat Exchanger Design: The heat exchangers in energy-saving air conditioners are designed to maximize heat transfer efficiency. This allows for better cooling or heating performance with less energy input, as the refrigerant can absorb or release heat more effectively.

Water-Cooling Air-Cooling And Evaporative Cooling In Industrial Air Conditioner For Optimal Cooling 0

Enhanced Insulation: These air conditioners often have better insulation materials and construction to prevent heat leakage or gain. This helps maintain the desired indoor temperature more easily, reducing the workload on the system and saving energy.

Energy-Efficient Industrial Eco-Air Conditioner

40% Less Energy Consumption: Significantly reduces operational costs with advanced energy-saving technology.
Quiet Operation: Low noise design—56 dB (indoor unit) & 63 dB (outdoor unit)—ideal for noise-sensitive environments.
Hybrid Cooling Technology: Combines water-cooling, air-cooling, and evaporative cooling for efficient heat dissipation.
Warm Air Exhaust: Emits (warm air) approximately 7°C above human body temperature, ensuring comfortable ambient air balance. Most importantly it's Eco-friendly at the same time.

This solution merges high efficiency, quiet performance, and innovative cooling to meet industrial needs while minimizing environmental impact.
